CMC S30 Access Platform – Maximum Height, Power, and Versatility in One Compact Machine

High-reach spider lift engineered for challenging terrain and professional use

The CMC S30 Access Platform is a high-performance tracked lift designed for operators who require exceptional reach, advanced capability, and dependable stability across all terrains. With its intelligent boom structure, three stabilisation areas, and climbing outriggers, it delivers remarkable performance in both standard and extreme work environments. As a result, this CMC S30 spider lift is trusted in arboriculture, construction, industrial maintenance, and facilities work where maximum height and precision are essential.

Outstanding Vertical Reach and Horizontal Performance

Offering a maximum working height of 30.3 m and an impressive lateral outreach of 15.4 m (with 80 kg), the CMC S30 Access Platform sets a new benchmark for spider lifts in its class. Furthermore, it can operate in negative working positions down to –6.7 m, making it suitable for applications such as bridge inspections and below-grade access. Even with its full 230 kg basket capacity, it maintains a reliable 12.4 m outreach, ensuring efficient two-man operation without compromising stability. Therefore, the CMC S30 tracked platform gives operators maximum flexibility in complex or hard-to-reach workspaces.

Advanced Boom Geometry for Full 3D Maneuverability

The S30 benefits from a refined boom system that includes a powerful articulated section, a long telescopic extension, and a ±90° jib for precise positioning at any angle. In addition, the turret provides ±200° rotation (400° continuous), giving full working coverage across the jobsite. Because of this highly responsive geometry, the CMC S30 Access Platform lets operators move seamlessly around obstacles, rooftops, and structural edges without constant repositioning.

Engineered for Stability and All-Terrain Operation

The CMC S30 spider lift is equipped with three dedicated stabiliser zones, allowing operators to select the optimal footprint depending on available space. Its climbing outriggers, as highlighted on page 1 of the spec sheet, ensure firm and safe anchoring even on uneven or sloped surfaces. Moreover, its slopes capabilities — including ramp attack of 10° to 17° and longitudinal travel up to 19° (34%) — enable reliable operation on construction sites, woodland ground, and industrial yards. Consequently, the platform maintains exceptional stability even in harsh terrain conditions.

Power Options Tailored for Every Environment

The CMC S30 Access Platform comes standard with the robust Kubota D902-E4B diesel engine (16.1 kW / 21.6 HP), providing excellent torque and fuel efficiency. Additionally, operators can choose from multiple power alternatives, including auxiliary 110/230 V electric motors, a 380 V electric option, a 48 V full-lithium system, or a hybrid diesel + lithium configuration. Furthermore, travel speeds reach up to 2.40 km/h, ensuring efficient repositioning between work areas. Because of these flexible power options, the S30 easily adapts to indoor, outdoor, or emission-restricted environments.

Designed for Productivity, Safety, and Long-Term Durability

Every detail of the CMC S30 Access Platform is built for longevity and operator comfort. Its reinforced structure, precision hydraulic controls, and ergonomic basket design reduce fatigue and enhance safety during prolonged work sessions. In addition, the platform’s compact 0.90 m width and 1.99–2.19 m height allow easy access to restrictive environments despite its significant working height. Therefore, the S30 remains one of the most versatile and dependable high-reach spider lifts available today.

Key Specifications

• Max. working height: 30.3 m

• Max. outreach: 15.4 m (80 kg) / 12.4 m (230 kg)

• Negative working capability: –6.7 m

• Platform height: 28.3 m

• Basket capacity: 230 kg

• Basket dimensions: 1.7 × 0.7 × 1.1 m

• Jib movement: ±90°

• Basket rotation: ±90°

• Turret rotation: ±200° (400° continuous)

• Total weight: 4,285 kg

• Stowed dimensions:

  • Length: 6.80 m (with basket)

  • Height: 1.99–2.19 m

  • Width: 0.90 m

• Slope capability:

  • Ramp attack (basket side): 10°/17°

  • Ramp attack (engine side): 7°/13°

  • Longitudinal travel: 19° (34%)

• Outrigger plate Ø: 0.24 m

• Ground pressures:

  • Foot: 5.84 kg/cm²

  • Tracks: 0.28 kg/cm²

• Power options:

  • Kubota D902-E4B diesel (16.1 kW / 21.6 hp)

  • Electric motors 110/230 V or 380 V

  • 48 V full-lithium (9 kW, 200 Ah)

  • Hybrid diesel + lithium

• Fuel tank: 30 L

• Travel speeds: up to 2.40 km/h (engine-dependent)

Summary

In summary, the CMC S30 Access Platform combines extreme working height, outstanding outreach, and full-terrain capability in a compact and highly engineered design. Thanks to its stabiliser versatility, powerful boom geometry, and flexible powertrain options, it delivers unmatched performance for demanding professional applications. Therefore, this CMC S30 spider lift is the ultimate choice for operators requiring maximum operational range, safety, and long-term durability in a single high-performance machine.

–
