New CMC i23 Access Platform 26546

Machine Details

Industry Arboriculture and Forestry, Construction
Condition New
Asset Type Access Platform
Hours/Mileage (or N/A?) N/A
Make CMC
Model i23
Age New
Seller type Dealer (Franchised)
Drive Type Tracked
Fuel or Power type Diesel, Electric
Stock id 26546
Features
  • 'Pay While You Earn' Payment Plans available
  • Franchised Main Dealer
  • Free Theft Protection HPI check by Arblease
  • HPI clear
  • Low and No Deposit
  • Low Fixed-Rate Finance Offer
  • Manufacturers Warranty
  • National Delivery Available
  • Part-ex considered
  • Remote Control
  • Spread/Finance/Defer the VAT
  • Tracked
  • Trailer Solutions

New CMC i23 Access Platform for sale

The CMC i23 Access Platform is a top-tier choice for those seeking exceptional reach and versatility in an access platform. Boasting a double pantograph geometric design, the CMC i23 offers the largest unrestricted outreach in its class, making it an outstanding option for various high-demand tasks. With a 23-metre working height and insulation up to 46 kilovolts, this platform ensures both reach and safety, making it ideal for diverse applications.

Transitioning to its features, the CMC i23 is equipped with three stabilization areas and automatic stabilizer leveling, which allow it to perform optimally under a wide range of conditions. This capability, combined with its robust design, makes it a reliable tool for challenging environments.

Key Specifications of the CMC i23 Access Platform

  • Working Height: 23M
  • Maximum Outreach: 10M at 12M height
  • Maximum Weight in Basket: 180Kg
  • Platform Rotation: 180 degrees
  • Slew Capacity: 400 degrees
  • Overall Weight: 3,930Kg
  • Stowed Dimensions: Length – 7.2M, Height – 2M, Width – 890mm (narrow) / 1.4M (wide)

Advanced Features for Enhanced Performance

The CMC i23 comes equipped with an array of advanced features designed to enhance its functionality and user experience. Powered by a Kubota D902 Diesel engine along with a 110v auxiliary electric motor and battery charger, this platform offers flexibility and efficiency. The hydraulically adjustable undercarriage, with black rubber tracks, allows for easy adaptation to different terrains.

The one-man fiberglass basket offers +/- 90° rotation via a hydraulic motor, ensuring precise positioning. Additionally, the basket is equipped with a 200 bar air/water hose and electrical sockets (230V/120V(predisposition)/110V and 24V) for versatile tool use. The platform’s protective cover for outriggers cylinders and a colour display for error code detection and machine status diagnosis ensure both safety and ease of use.

Innovative Control and Safety Systems

The CMC i23 is designed with advanced control systems, including proportional electro-hydraulic controls and the Self-Control System by CMC, which features automatic outrigger leveling, turret centering, and speed control for maneuvers. The platform also includes an automatic anti-collision system and a block for drive on over-maximum gradient conditions, enhancing operational safety.

For remote operation, the CMC i23 offers radio remote controls with a colour display and multiple outrigger position settings, further increasing its versatility. The platform is also equipped with a remote connection via SIM card and GPS locator, enabling real-time monitoring and diagnostics.

Backed by a full manufacturer’s warranty and available in standard painting (RAL 3000), the CMC i23 Access Platform represents a comprehensive solution for high-reach, high-safety applications.

In summary, the CMC i23 Access Platform is a cutting-edge tool designed for maximum efficiency, safety, and ease of use, making it an excellent choice for professionals needing reliable and versatile access solutions.
