New Tajfun RCA 480 Joy Wood Processor 697929

Machine Details

Industry Arboriculture and Forestry
Condition New
Asset Type
Hours/Mileage (or N/A?)
Make Tajfun
Model RCA 480 Joy
Age New
Seller type Direct
Drive Type PTO
Fuel or Power type N/A
Stock id 697929
Features

New Tajfun RCA 480 Joy Wood Processor 697929

Let's find out what they have to say about this machine...

The Tajfun RCA 480 comes with a swinging outfeed and 4/6 way combined splitter.  480 mm capacity.

MACHINE SPECIFICATION:

Length of Cut Log: 25 – 50 cm
Max. Diameter of Log: 5 – 48 cm
Sawbar: Oregon 24˝, b = 1,5 mm
Chain: 3/8˝Oregon DuraCutTM
Splitting Force: 250 kN – Two Splitting Speeds
Width x Length x Height (at 45° Incline of the Conveyor): 6100 x 1600 x 3150 mm
TT 504 – 6930 x 1600 x 3800 mm
Width x Length x Height (Transport Position): 2410 x 1600 x 2330 mm
TT 504 – 2410 x 1600 x 2630 m
Weight with Discharge Conveyor: 1300 kg + 180 kg (TT504 210 kg)
Required Tractor Capacity: 30 kW (Transport 60 – 70 kW)
Inbound PTO Shaft Speed: 400 – 430 min-1
Discharge Conveyor with Two Stage Telescope with Automatic Hydraulic Belt Straining.
Length of Discharge Conveyor: 4 m (TT 504 – 5 m)
Belt Width: 43 cm
Belt Speed (Continuous Speed Control): 0 – 0,8 m/s
Weight of Discharge Conveyor: 180 kg (TT 504 210 kg)
PTO drive shaft (three-point-connection; recommendable tractor power for the machine- driving – 30 kW;
for transport – 60 kW).
Oil cooler with thermostat assures reliable machine operation even at higher temperatures: Option – 5 m conveyor TT 504
Option – Discharge Conveyor TT 510 R or TT 510 S
