| Maximum load |
8.5 ton |
10.0 ton |
11.0 ton |
| Standard crane; it is possible to install a crane up to 7.5 m |
5.3 m |
6.4 m |
6.7 m |
| Effective load area |
1.80 m2 |
2.35 m2 |
2.35 m2 |
| Chain saw box |
Extra equipment |
Yes/standard |
Yes/standard |
| Gate |
Yes/standard |
Yes/standard |
Yes/standard |
| Gate height |
1100 mm |
1400 mm |
1400 mm |
| Stake height |
1100 mm |
1400 mm |
1400 mm |
| Dimensions on stakes |
89 x 6 mm |
89 x 6 mm |
89 x 6 mm |
| Stake extensions |
No, stakes are in one piece |
No, stakes are in one piece |
No, stakes are in one piece |
| Divider stakes, for timber sorting |
Extra equipment |
Extra equipment |
Extra equipment |
| No. of bolsters |
2 |
3 |
3 |
| More bolsters can be fitted |
Yes |
Yes |
Yes |
| Hydraulic support legs |
Yes/standard folding legs |
Yes/standard folding legs |
Yes/standard folding legs |
| Telescopic support legs |
Extra equipment |
Extra equipment |
Extra equipment |
| Trailer steering |
Yes/standard |
Yes/standard |
Yes/standard |
| No. of steering cylinders |
1 |
2 |
2 |
| Max. steering angle |
40° to both left and right |
40° to both left and right |
40° to both left and right |
| Towing eye to tractor |
Forged towing eye for hitch connector |
Forged towing eye for hitch connector |
Forged towing eye for hitch connector |
| Lubricatable bushings or link bearings in all joints |
Yes/standard |
Yes/standard |
Yes/standard |
| Diameter of steering pivot |
70 mm |
70 mm |
70 mm |
| Bogies |
Yes/standard |
Yes/standard |
Yes/standard |
| Tip angle of bogies |
+/- 30° |
+/- 30° |
+/- 30° |
| Axle separation |
995 mm |
995 mm |
995 mm |
| Distance on bogie from centre of front axle to centre of pivot |
530 mm |
530 mm |
530 mm |
| Track width |
1622 mm |
1622 mm |
1622 mm |
| Tyre size standard |
400/60 x 15.5 |
400/60 x 15.5 |
400/60 x 15.5 |
| Other sizes available to order |
14-ply |
14-ply |
14-ply
Tractor tread |
| Brakes, drum or disc |
Extra equipment |
Extra equipment |
Extra equipment |
| Number of hydraulic outlets required |
2 double-acting
Extra equipment available to enable use with 1 single-acting and 1 return. |
2 double-acting
Extra equipment available to enable use with 1 single-acting and 1 return. |
2 double-acting
Extra equipment available to enable use with 1 single-acting and 1 return. |
| Brake hoses run fully protected in frame or substantial steel tubes |
Yes/standard when trailer is fitted with brakes |
Yes/standard when trailer is fitted with brakes |
Yes/standard when trailer is fitted with brakes |
| Support foot |
Yes/standard |
Extra equipment |
Extra equipment |
| Hydraulic wheel drive |
Extra equipment |
Extra equipment |
Extra equipment |
| Stub shaft dimension |
70 x 70 mm |
80 x 80 mm |
80 x 80 mm |
| Central frame of special steel |
180 x 180 x 5 mm |
180 x 180 x 8 mm |
180 x 180 x 10 mm |
| Loading width at bottom of load area |
910 mm |
910 mm |
910 mm |
| Loading width at top of stakes |
1830 mm |
1830 mm |
1830 mm |
| Loading width at top of stakes for brushwood equipment |
3000 mm |
3000 mm |
3000 mm |
Overall height including crane at hitch height 400 mm
(This dimension depends on the height of the tractor hitch hook) |
About 2668 mm |
About 2968 mm |
About 2773 mm |
| Recommended tractor power for full load |
45 hp and up |
60 hp and up |
65 hp and up |
| Weight, complete timber trailer |
2170 kg |
2345 kg |
2570 kg |
| Weight complete, without crane and 3-point adaptor |
1360 kg |
1495 kg |
1555 kg |
