New Platform Basket Spider 22.10 Evo Access Platform 697879

Machine Details

Industry Arboriculture and Forestry
Condition New
Asset Type Access Platform
Hours/Mileage (or N/A?)
Make Platform Basket
Model Spider 22.10 Evo
Age New
Seller type Direct
Drive Type Tracked
Fuel or Power type Diesel
Stock id 697879
Features

New Platform Basket Spider 22.10 Evo Access Platform 697879

Let's find out what they have to say about this machine...

KEY FEATURES:

• Road towable by lightweight trailer behind a 4×4 or van
• Cranked outrigger design for increased ground clearance
• Multi-position stabiliser set up
• Cage rotation
• Quick and easily detachable cage
• Hydraulic track widening and lift system
• Kubota diesel engine
• AC mains electric for indoor or silent works
• Features
• Lithium/hybrid battery option
• Non-marking rubber tracks
• Two speed tracking
• Fibreglass cage option
• Auto set-up
• Radio controls
• Simple intuitive operating system
• Air/water and power line to cage

An Industry-leading compact tracked chassis access platform, the EVO version features the very latest user-friendly operating features. With a double riser articulating boom plus telescopic boom and versatile fly-jib, for smooth and stable operation, it is quick and easy to set-up and start working, whilst providing a big extreme maximum working outreach.

Dual power options make this highly manoeuvrable all-rounder, with multi-position stabilisers, perfect for internal and external works, including poor terrain, owing to the extreme ground clearance and longer track base that provides greater stability. Can be safely manoeuvred at a distance using the radio control system. A strong machine, with exposed parts securely protected by metal guards.

MACHINE SPECIFICATION:

Working Height: 21.7 m
Max Outreach: 10.2 m
Max Cage Capacity: 230 kg
Cage Size: 1,500 mm x 700 mm x 1100 mm
Weight: 2,980 kg
Length: 5,970 mm (5,280 mm with cage removed)
Stowed Width: 980 mm
