ARBMAX D35 13″ Drum Tracked Wood Chipper – Compact 13″ Drum Chipper with Big-Site Performance

High-output chipping in a tracked, trailer-friendly package.

The ARBMAX D35 13″ Drum Tracked Wood Chipper is designed for professional arborists, forestry teams and land clearance contractors who need 13″ capacity performance in a compact, easily transported machine. With a 75hp Stage V diesel engine, aggressive dual-drive feed and a remote-operated tracked undercarriage, the ARBMAX D35 13″ Drum Tracked Wood Chipper delivers serious throughput without the bulk of larger chippers.

75hp Stage V Diesel Power with Compact Transport Weight

Powered by a 75hp / 55kW Deutz Stage V diesel engine, the ARBMAX D35 13″ Drum Tracked Wood Chipper handles demanding workloads with confidence. The engine is tuned to deliver strong torque for heavy, continuous feeding, so you keep chipping even when the material gets knotty or awkward.

Despite its capability, the chipper’s basic weight is around 2,700kg, which allows it to sit within standard plant trailer limits when configured correctly. As a result, the D35 offers genuine tracked performance while still being practical to move between sites.

Large Feed Opening and Aggressive Dual-Drive Feed Wheels

The infeed on the ARBMAX D35 13″ Drum Tracked Wood Chipper is built for productivity. A feed opening of 350mm x 450mm gives ample room for 13″ material, awkward forks and heavy brash. The oversized folding hopper is designed to make hand feeding easier and more efficient on busy days.

A dual-drive feed system with Hardox-toothed feed wheels delivers strong pulling and crushing power. Consequently, the chipper drags in timber rather than needing constant pushing, which reduces operator fatigue and speeds up work on difficult jobs. Auto-infeed management helps keep the machine running at an efficient load level.

Drum Rotor, Hardox Chamber and Biomass Screen

At the heart of the chipper is a three-knife drum rotor set within a Hardox® chipping chamber. This combination gives consistent chip quality and long component life, even in demanding conditions. The system also includes a quick-change knife setup and a biomass screen (G50 style on many specs), so you can maintain or adjust chip spec with minimal downtime.

Because the chamber uses Hardox and wear liners in key areas, it resists abrasion and impacts far better than lighter designs, which is important when you chip mixed material day after day.

Remote-Operated Tracked Undercarriage

The ARBMAX D35 13″ Drum Tracked Wood Chipper runs on a remote-operated tracked undercarriage with a track width of approximately 1,500mm. This gives good stability and ground clearance on rough, rutted or uneven sites, while still fitting onto standard plant trailers.

Remote control tracking lets the operator position the chipper exactly where it is needed, even on banks, rides and tight access points. As a result, you can reduce dragging distance and set up safer, more efficient worksites.

Safety, Control and Operator Interface

Because safety and control matter as much as power, the ARBMAX D35 13″ Drum Tracked Wood Chipper is equipped with:

• An auto-infeed system to manage load on the rotor

• An oversized folding hopper with triple safety stop bars for safer hand feeding

• Dual multifunction control panels at the rear

• Multiple emergency stop buttons for rapid shutdown

An intuitive HD colour HMI display provides clear system status and control icons, while two selectable chipping modes (Logs & Brash) allow you to fine-tune performance for different material types. This helps operators get the most from the machine without constant tweaking.

✅ ARBMAX D35 13″ Drum Tracked Wood Chipper – Key Features

• ✅ Engine: 75hp / 55kW Deutz Stage V diesel

• ✅ Chipping System: 3-knife drum rotor with Hardox chamber and biomass screen

• ✅ Feed Opening: 350mm x 450mm

• ✅ Feed System: Dual-drive Hardox-toothed feed wheels with auto-infeed

• ✅ Hopper: Oversized folding hopper with triple safety stop bars

• ✅ Weight: Approx. 2,700kg (tracked, transport-friendly)

• ✅ Track Width: Around 1,500mm with high ground clearance

• ✅ Control: Remote-operated tracked undercarriage, HD colour HMI display

• ✅ Modes: Two chipping modes – Logs & Brash

• ✅ Best For: Professional arb teams, forestry contractors and land clearance work needing a compact yet powerful 13″ tracked chipper

–
