New Toro Dingo TX 1300 Mini Loader 15910

1 Video

Machine Details

Industry Arboriculture and Forestry, Construction, Farming, Groundcare
Condition New
Asset Type Mini Loader
Hours/Mileage (or N/A?) N/A
Make Toro
Model Dingo TX 1300
Age New
Seller type Direct
Drive Type Tracked
Fuel or Power type Diesel
Stock id 15910
  • Additional attachments
  • Direct from manufacturer
  • Free theft protection HPI check by Arblease
  • Low and No Deposit
  • Low Rate Finance Offer
  • Manufacturers Warranty
  • National Delivery
  • Quarterly finance payment plans available
  • Seasonal finance payment plans available
  • Specialist farm finance payment schemes available
  • Tracked
  • Trailer Solutions Available
  • VAT Deferral Available

New Toro Dingo TX 1300 Mini Loader 15910

Let's find out what they have to say about this machine...


For sale a New Toro Dingo TX 1300 Tracked Compact Utility Loader

New Toro Dingo TX 1300 Tracked Compact Utility Loader is ideal for landscape, hardscape and tree care jobs, the TX 1300 brings a new combination of power, reach and convenient control to the Toro® Dingo® lineup.

Yanmar® Tier IV diesel engine

With a 37 hp Yanmar® Tier IV diesel engine and 1,300 lbs of rated operating capacity, it’s the user-friendly workhorse you need to save time. The exclusive INTELESCOPE® loader arm with SmartLoad adds 26″ of reach, and the telescoped hinge-pin height of 109″ means you can lift loads up and over the side of a dumpster or truck for maximum productivity.

One hand and thumb-controlled

Plus, you can operate the Toro patented traction controls with one hand and thumb-controlled telescoping extension and auxiliary functions (in the loader arm control) with the other to pick, place and dump materials with ease all day long.


Check out the video:

  • Air Filter Remote dual element
    Dump Angle 38 degrees
    Dump Height (cm) 230.3
    Dump Height (inches) 90.7
    Engine Make Yanmar
    Fuel Tank (gallons) 11
    Fuel Tank (liters) 42
    Fuel Type Diesel
    Ground Clearance (cm) 15
    Ground Clearance (inches) 5.9
    Ground Pressure 5.5 psi
    Ground Speed Forward (mph) 4.7
    Ground Speed Foward (km/h) 7.6
    Ground Speed Reverse (km/h) 7.6
    Ground Speed Reverse (mph) 4.7
    Hinge Pin Height (cm) 277.4
    Hinge Pin Height (inches) 109.2
    Hydraulic Flow Auxilary 14.3 gpm
    Hydraulic Flow Traction 13.4 gpm (each pump)
    Hydraulic Pressure 3,200 psi
    Loader Arms Radial
    Manufacturer’s Gross HP Rating (HP) 37
    Manufacturer’s Gross HP Rating (kW) 27
    Max Operating Height (cm) 337.8
    Max Operating Height (inches) 133
    Oil Capacity (liters) 4.7
    Oil Capacity (quarts) 5
    Overall Height (cm) 143.5
    Overall Height (inches) 56.5
    Overall Length w/bucket (cm) 262
    Overall Length w/bucket (inches) 103.1
    Overall Length w/o bucket (cm) 215.6
    Overall Length w/o bucket (inches) 84.9
    Overall Width (cm) 116.8
    Overall Width (inches) 46
    Rated Operating Capacity – 35% of Tip Capacity (kg) 590
    Rated Operating Capacity – 35% of Tip Capacity (lbs) 1300
    Reach – Fully Raised (cm) 67.8
    Reach – Fully Raised (inches) 26.7
    Reservoir Capacity (gallons) 9.2
    Reservoir Capacity (liters) 34.8
    RPM 3000
    Tip Capacity (kg) 1685
    Tip Capacity (lbs) 3714
    Track Length (inches) 126.6
    Track Length(cm) 322
    Track Width (cm) 23
    Track Width (inches) 9.1
    Tracks MERT track with “TF” style tread
    Traction Dual Hydrostatic Pump
    Weight (kg) 1750
    Weight (lbs) 3858
    Wheelbase (inches) 39
