New Leguan 190 Access Platform for sale.

Leguan Lifts – Straight to the Point

LEGUAN LIFTS specializes in designing and manufacturing reliable and technologically advanced self-propelled access platforms. Leguan has a long tradition in this field; the first self-propelled access platform with outriggers was introduced in 1994. Leguan Lifts is part of the fast-growing Avant Tecno Group from Finland.

Leguans versatile and fit for any access job

Every spider lift is designed with extraordinary all-terrain capabilities and robust boom structure, which makes Leguans versatile and fit for any access job. Leguans are built to withstand all climates from the heat of Australia to the freezing cold winters of the Nordics. In recent years, Leguan Lifts has completely restructured their product selection introducing many unseen features and the most user-friendly interface to date.

• Unrivalled all-terrain capabilities
• Robust boom construction and protected chassis
• Efficient hydraulics for simultaneous multi-boom operation
• Industry-leading side reach and up and over clearance
• Highest standard of safety and user-friendly design

Versatile.

Leguan spider lifts are known for their exceptional off-road capabilities, and industry-leading gradeability. Sturdy track or tire chassis with leading ground clearance and travel speeds ensure rapid transitioning through snow or mud. The fuel-efficient combustion engine and silent electric operation makes Leguan a great fit for both inside and outside use, and the compact size makes transportation easy.

Intuitive and user-friendly.

Advanced hydraulic design allows smooth and simultaneous boom movements, which makes it easy to maneuver Leguans in narrow places and maintain distance to walls. The new Leguan spider lifts are equipped with user-friendly features such as automatic levelling that allows effortless outrigger levelling with just a single push of a button, even on challenging terrain.

Next generation features.

Both the safety features and the proportional outreach monitoring system are controlled by a modern PLC that ensures the highest standard of safety combined with unrivalled outreach in all situations. Leguan Lifts lead the way with superior industrial design, numerous technological innovations and smart energy saving functions, which provide Leguans with high resale values over time.

Options

Leguan spider lifts are always well-equipped and come with many advanced features as standard to ensure the highest efficiency. However, you can equip your own Leguan with many additional features to match the requirements of your line of work or job sites.

Some of the most popular optional features are the LED lighting for the operating panel, which allows better visibility of the controls in darker conditions, and the outrigger beacons that improve work safety. Inquiry more about the standard and optional features from your local Leguan dealer.

TECHNICAL INFORMATION – LEGUAN 190

• WORKING HEIGHT 19 m
• SIDE REACH 9.8 m
• LIFT CAPACITY 230 kg
• PLATFORM HEIGHT 17 m

ROBUST AND STEADY SPIDER LIFT WITH ALL-TERRAIN CAPABILITIES

LEGUAN 190 is an access platform designed for heavy duty professional and rental use. In the design of the spider lift, special attention has been paid to durability, excellent up-and-over clearance and user-friendly interface. Leguan 190 is the right choice for tree care, painters, construction work and facility maintenance.

High ground clearance and steady, protected tracked (or 4WD) base provide fast and smooth access on rough terrain. All Leguans are designed to be driven safely while standing on the platform to increase efficiency while transitioning on site. Many leading features such as the automatic levelling is standard, but operators can also opt for many optional features such as the extra speed for the fastest driving speed in the market.

TECHNICAL FEATURES

• LIFT CAPACITY 230 kg (2 persons)
• WORKING HEIGHT 19.00 m
• PLATFORM HEIGHT 17.00 m
• OUTREACH 8.1 m (230 kg) –
• 8 m (120 kg)
• TRANSPORT DIMENSIONS, L X W X H 5.1 x 1.33 x 2.01 m
• PLATFORM DIMENSIONS 1.33 x 0.75 m
• ROTATION OF THE PLATFORM 90º (±45º)
• SLEWING 360º
• GRADEABILITY 40% (22º)
• DIMENSIONS W/O PLATFORM, L X W 4.44 x 1.25 m
• OUTRIGGER SUPPORT DIMENSIONS 3.60 x 3.69 m
• SLOPE FOR OUTRIGGERS 21% (12º)
• WEIGHT 2.660 kg
• ENGINE : Kubota 14 hp diesel or 230 V / 2.2 kW electric
• DRIVE SYSTEM: HYDRAULIC4WD / tracks
• DRIVE SPEED 2.6 km/h (5.2 km/h option)

Standard features

• 14 hp Kubota diesel + 230 V electric motor
• 230 V and 12 V power outlets on platform
• Automatic engine RPM control
• Automatic leveling of the outriggers
• Proportional outreach monitoring system
• Electric rotation of the platform
• JIB-boom with 120 degree operating range
• Electric and hand pump powered emergency lowering
• Lower controls with integrated service display
• 12 V booster points
• Optional features
• Extra drive speed (max. 5.2 km/h)
• Remote control for driving and outriggers
• Platform control panel lighting and LED spotlights
• Tool trays on platform
• Outrigger beacons
• Hose to platform (air/water)
• Signal horn
• Engine heater
• Larger plates for outriggers
• Non-marking tracks / tyres
• Narrow single person platform
• Leguan special trailer

–
