The B13-90 is a compact and user-friendly stump grinder. With a width of only 77 cm you pass this machine without any problem through all doors and garden gates. The grinding arm can be moved easily thanks to the hinge system and grinds 90 cm wide and 35 cm deep. Following performance examples (average values):
› ø300 mm: 10 min
› ø600 mm: 25 min
› ø1000 mm: 90 min
Greenteeth
The Greenteeth® teeth can be easily turned 3 x (120°) and can be ground afterwards. The control tree of the B13-90 can be easily put higher or lower for a more ergonomic work. Also ideal for transport and perfect for rental companies.
The build
All Jo Beau machines are built according to the valid European guidelines and have a CE-certificate. All machines are supplied with manual and parts list.
Key features
✓ Compact for transport
✓ Easy manual operation
✓ Big air tires
✓ Only 77cm wide
✓ Disc transmission by industrial powerbelt
✓ Centrifugal coupling
✓ Teeth can be turned 3 x 120° and can be ground again
✓ The machine has a lifting eye
MACHINE SPECIFICATION:
Performance
| Max. working width: |
900 mm (35.43 in) |
| Max. grinding depth: |
350 – 400 mm (13.78 – 15.75 in) |
| Max. grinding height: |
350 – 400 mm (13.78 – 15.75 in) |
| Control: |
Manual |
Engine
| Drive: |
Petrol engine |
| Brand & type: |
Honda GX390 – 1 cyl. 4-stroke |
| Power: |
8,7 kW (13 hp) |
| Consumption: |
3,5 l/h – 3600 rpm |
| Noise level Lw(A): |
100 dB(A) |
Design
| Dimensions (LxWxH): |
2100 x 770 x 1200 mm (82.7 x 30.3 x 47.2 in) |
| Weight: |
151 kg (332.89 lbs) |
| Brakes: |
Two independent brakes |
| Chassis: |
Powder-coated steel |
| Grinding Technology: |
Jo Beau® grindertechnology™ |
| Teeth: |
Greenteeth® 700, 8 pcs |
| Grindwheel diameter: |
340 mm (13.38 in) |
| Disc transmission: |
Industrial powerbelt on centrifugal clutch |
| Foldable & height-adjustable handlebar: |
Standard |
Options
| Maintenance alarm /hour counter: |
✓ |
| Set leakproof wheels: |
✓ |
| Tow bar: |
✓ |
| Set mudguards: |
✓ |
–
