Over 200 attachments available! Just awesome!
Excellent choice with robust and simple hydraulics
The 500 series is in the middle of Avant loader range in terms of size and performance. The 500 series loaders are well suited for a wide range of customer segments thanks to their power and straight forward hydraulics which is needed in many jobs. The compact dimensions and good maneuverability allow working in a large variety of environments. 500 series can also lift amazingly heavy loads compared to the size of the machine.
Avant 500 series is a reliable partner for all-round use. Like all Avants, it can be equipped following customer needs, including all cab options (L, LX, DLX). The comprehensive Avant attachment range guarantees efficient working all year round.
- Lift capacity 800-950 kg
- Lift height 2.8 m
- Engine power 22-26 hp
- Drive speed 12-19 km/h
Optidrive™ drive circuit gives more power for the drive and hydraulic attachments.
Simple, effective hydraulics means good power and low operating costs
Easy to transport with a car trailer
Machine specifications:
- Lift Capacity:950
- kgEngine Power:26 hp diesel
- Lift Height:2,8 mSpeed:10 km/h
- Length:2550 mm
- Width:1140.46 mm
- Height:1980 mm
- Weight:1250 + 170 kg
- Standard wheels:23×10.50-12”grass/TR
- Transmission, drive:hydrostatic
- Pulling force:950 kp
- max Drive speed:10 km/h
- Aux. hydraulics oil flow / pressure:36 L/min 200 bar
- Turning radius – inside:995 mmoutside:2050 mm
- Max. lifting height (with telescopic boom):2790 mm
- Tipping load:950 kg (Load is measured at 400 mm from the attachment coupling plate, including attachment weight (70 kg).)
- Max. breakout force / 50 cm:2800 lb
- Engine make and type:Kubota D1105
- Engine output (ISO Gross):25 hp
- Fuel:Diesel
–
