Jekko SPX532.2CDH Mini Crane

The Jekko SPX532 Mini Crane is a compact tracked crane designed for professional lifting operations where access, lifting capacity and versatility are essential. Importantly, with a maximum lifting capacity of 3,200kg and an overall width of just 770mm, this powerful spider crane can reach working areas that may be inaccessible to larger lifting equipment.

Powered by a Kubota D902-K Stage V diesel engine, the Jekko SPX532.2CDH also features a 110-220V Bi-Energy electric pack. Therefore, operators have the flexibility of diesel power alongside plug-in electric operation when required.

Key Features

• Maximum lifting capacity: 3,200kg
• Maximum working height: 17.3m
• Maximum radius: 14.8m
• Compact 770mm overall width
• Kubota D902-K 18.5kW diesel engine
• Stage V / Tier IV Final engine
• 110-220V Bi-Energy electric pack
• Jekko Intelligent Multi Speed Power Control
• Five-section main boom
• Main boom maximum height: 11.8m
• Hydraulic telescopic/luffing fly jib
• Maximum height with fly jib: 17m
• Radio remote control
• 7-inch shockproof IP66 touchscreen interface
• 360-degree slewing
• Pick & Carry capability
• Working Range Limitation / Virtual Wall
• 800kg capacity winch with 80m rope
• 1-ton single-line hook
• 4-ton two-sheave hook
• 1,200kg SWL runner jib
• Independently extendable tracks with 45-degree angle
• 400 x 400mm outrigger mats
• Compatible with Jekko Plug & Play attachments
• 2-year full parts and labour warranty
• 2 days familiarisation training

Compact Access and Serious Lifting Performance

At only 770mm wide, the Jekko SPX532 Mini Crane combines impressive lifting performance with exceptionally compact dimensions. As a result, it is well suited to restricted-access lifting jobs and locations where conventional cranes may be difficult to position.

The independently extendable tracks further increase its versatility. In addition, 360-degree slewing and Pick & Carry capability provide greater flexibility when lifting and positioning loads around a working site.

Diesel and Electric Operation

The Kubota diesel engine provides dependable power for demanding lifting applications. However, the additional Bi-Energy electric pack allows the crane to be plugged into a 110V or 220V electrical supply when required.

Consequently, this compact crane can provide businesses with additional flexibility across different working environments and applications.

The Jekko SPX532 Mini Crane also features radio remote control and a 7-inch touchscreen user interface. Furthermore, the shockproof display carries an IP66 rating for use in demanding working conditions.

Versatile Spider Crane

With a five-section main boom and hydraulic telescopic/luffing fly jib, the SPX532.2CDH provides excellent reach from a remarkably compact machine. For example, maximum working height reaches 17.3m, while maximum radius extends to 14.8m.

Working Range Limitation, also known as a Virtual Wall, provides additional control over the crane’s operating area. Additionally, compatibility with Jekko Plug & Play attachments allows the machine to be configured for a variety of professional lifting applications.

For further manufacturer information, visit the official Jekko website.

Mini Crane Finance Available

Arblease can provide finance for the Jekko SPX532 Mini Crane, as well as other new and used mini cranes, spider cranes, tracked cranes and specialist lifting equipment. Therefore, businesses can spread the cost of acquiring specialist machinery while preserving working capital.

This machine may be particularly attractive to businesses searching for a Jekko mini crane, 3.2 tonne mini crane, compact spider crane, tracked mini crane, Pick & Carry crane or restricted-access lifting crane.

You can get a machinery finance quote from Arblease to explore available finance options.

Finance is subject to status and approval.

–
